Orno DG 100

100mm x 25mm (Double glaze)

Available in two colors

Technical Details

Optimum transparency while maintaining privacy

The ORNO DG 100 demountable office partition provides excellent acoustic values. It is based on a 100mm x 25mm double glazing seal and bead with a selection of door frame options.

Features

  • Standard track section : 100mm x 25mm
  • Slim in design, the standard partition suite can be used with any stud thickness
  • Suitable for 10mm / 12mm toughened glass as well as 10.52mm / 12.52mm laminated glass
  • Single door frame sizes to allow for flush door 35mm or 45mm
  • Partition height can be offered up to 3000mm
  • Single glazed systems
  • Sound insulation capacity of 46 - 49 dB

Optimum transparency while maintaining privacy

The ORNO DG 100 demountable office partition provides excellent acoustic values. It is based on a 100mm x 25mm double glazing seal and bead with selection of door frame options.

Door Options

Frame less glass, Stile glaze door, Timber or Sliding door system

Timber doors can be of 44mm solid core in choice of veneers

Aluminium full height up to 3000mm, doors are mounted on either hinges, pivot or sliding tracks. A range of Ironmongery can be supplied and incorporated with respected series.

Designed for installation in areas up to nominal vertical panel size of 3000mm x 1200mm

All exposed aluminium sections are anodized aluminium finish with 6463 T6 Grade

Laminate, Melamine, Whiteboard, Veneer, Vinyl, Powder Coated Steel and Pinnable Fabric. These finishes can be applied in any combination.These finishes can be applied in any combination.

Glazed panels are hung onto a site installed framework of recessed head, side walls and base channels, studs and transoms. Base tracks have a snap in profile for better installation of glass into section using beads made of silicone gel material and choice of junctions available. Assembly jig supplied ensures the speed and accuracy of the installation and correct alignments of panel. All panels can be removed independently of each other allowing replacement or variation at any time after initial installation.
